Jual Flow Meter GPI 1,5 Inch MR 5-30N

Katalog :
Katalog GPI Fuel Meters MR5-30
Mechanical Fuel Meter GPI MR5-30
Mechanical Fuel Meter calibrated in gallons with 1 ½ in. NPT thread inlet/outlet. UL Listed. 5 to 30 GPM / 19 to 114 LPM.
 Specifications

Design Type

Mechanical Nutating Disc

Fitting

NPT

Mechanical Connection

1 ½ in. Inlet
1 ½
in. Outlet

Flow Range

5 to 30 GPM
19 to 114
LPM

Accuracy

±2 % of reading

Operating Temperature

-20 to 125 ºF
-29 to 52
ºC

Display

Mechanical
Batch: 4; Total: 8
Digits

Reads

Gallons or Litres

Wetted Materials

Nickel Plated Housing

Pressure Rating

3.4 bar
50
PSI

Model

MR 5-30N

To Use With

Diesel
Gasohol (Gasoline/Ethanol blends – E10 maximum)

Gasoline

Kerosene

Do Not Use With

Water or chemicals

Unique Features

Fluorocarbon seals and stainless steel hardware

Approvals

View

U.L. Listed on NPT Models

Warranty

2 years



Deskripsi

GPI MR 5-30 Mechanical Nutating Disc Flow Meter

Choose the MR 5-30 when you need to meter petroleum fuels. The Aluminium meter is perfect for use with gasoline (alcohol blends up to E15), diesel and kerosene.

Designed for high volume pumps.

Can measure in US Gallons or Litres

Available with either 1″  or  1.5″ BSP ports.

  • 5 to 30 GPM or 19-114 lpm Flow rate
  • +/- 2% Accuracy
  • Maximum working pressure 50 PSI or 3.4 Bar
  • Threads NPT or BSPP
  • Max Batch Total – 999.9 US Gallons or 9,999 Litres
  • Max Cumulative Total – 999,999.9 US Gallons or 9,999,999 Litres
  • Rotatable Cover for verticle or horizontal direction of flow
