Turbine Flow Meter NITTO SEIKO Type KA 75 Size 3 Inch

Katalog :
Turbine Flow Meter NITTO SEIKO KA,KC,KH,KZ,KI

Jual Turbine Flow Meter NITTO SEIKO Type KA 75 Size 3 Inch (75 mm)

General Specifications
Figures in parenthesis are for special specification.
Measured liquid  :Tap water, Industrial water, Underground water, Cold and hot water, Drain water, Sea water
Size : 50A, 80A, 100A, 125A, 150A 200A, 250A, 300A, 350A, 400A
Liquid temp : Normal temp. ～80°C（0～150 °C）
Liquid pressure : 1.0MPa or less（2.0MPa or less）
Accuracy : Within ±2.0%
Material : FC200/CAC406 FC200/SCS13 SCS13/SCS13
Kategori: Tag: , , , ,

Deskripsi

  • Distributors NITTO SEIKO Indonesia
  • Flow Meter Minyak NITTO SEIKO
  • Flow Meter NITTO SEIKO
  • Jual Flow Meter NITTO SEIKO Japan
  • Oil Flow Meter NITTO SEIKO Type KA, KC, KH, KZ, KI
  • Flow Meter Nitto SEIKO Type KA75, KA 75 Size 3 Inch (75mm)
  • Ready Stock Nitto Seiko KA Turbine Flow Meter
■Specification
Measured liquid Tap water, Industrial water, Underground water, Cold and hot water, Drain water, Sea water
Nominal size 50～400 mm
Liquid temperature 0～60℃, 60～150℃ (High temperature specification)
Liquid pressure 1.0 MPa or less (2.0MPa or less by Flange standard)
Accuracy Within ±2.0%
