Gas Meter GTEC G 6 Size 1 inch-Flow meter gas gtec g-6
The Spec of GTG_G4 / GTG_G6
Sort The Spec of GTG G4 The Spec of GTG G6
Maximum utility flux (m3/h) 6 10
Minimum utility flux (m3/h) 0.04 0.06
Maximum utility pressure (kPa) 100
DEV (dm3/Rev) 1.0
Maximum indication (m3) 9999.999 99999.999
Minimum indication (dm3) 0.2
Measurement accuracy (%) Qmin ≤ Q < 0.1Qmax: ±3.0%, 0.1Qmax ≤ Q ≤ Qmax: ±1.5%
Input + Output direction Left, Right
Input + Output distance (mm) 130
Input + Output screw thread M34X1.5P
Utility temperature -20oC ~ +60 oC
Weight (kg) 1.70
Utility gas LNG, LPG
Accessory Union (PT3/4inch)
Union nut (M34XP1.5), Closed gasket, The support Bolt
