Jual Flange Mounted SHM Differential Pressure Transmitter Flush Type DN50 – 80

Katalog : Flange Mounted SHM Differential Pressure Transmitter Flush Type PDF

SPECIFICATION
Size : DN 50 – 80
Material : Head Epoxy Coated Aluminium, Body SS316L, Flange SS316L
Temperature : 0-250c
Pressure : 100 kPa
Power Suply : 24 VDC
Output : 4-20 mA HART
Protection Grade : IP 67
Connection : Flange PN16
Accuracy : 0.075%
Measurement Range : 1-100 Kpa
Stability : 0.1% per Years
Response Time : 120 ms
Repeatibility : –
Explosion Proof : –
Exida & TUV SIL2/ SIL3 Certified
Warranty 2 Years ( Full Service & Spare Parts )

Deskripsi

SPECIFICATION
Size : DN 50 – 80
Material : Head Epoxy Coated Aluminium, Body SS316L, Flange SS316L
Temperature : 0-250c
Pressure : 100 kPa
Power Suply : 24 VDC
Output : 4-20 mA HART
Protection Grade : IP 67
Connection : Flange PN16
Accuracy : 0.075%
Measurement Range : 1-100 Kpa
Stability : 0.1% per Years
Response Time : 120 ms
Repeatibility : –
Explosion Proof : –
Exida & TUV SIL2/ SIL3 Certified
Warranty 2 Years ( Full Service & Spare Parts )

APPLICATION
Measure differential pressure of Gas, Air, Steam, Liquid, Water, Various Solution, Spcial Fuild
