Deskripsi
Blue White – Digital Paddlewheel Flowmeter F-1000 Saddle Mount Fittings
description :
| Water Ranges 15 to 8,000 GPM (70 to 27,000 LPM) |
| Pipe Sizes 1½”, 2″, 2½”, 3″, 4″, 6″, 8″, 10″, 12″ |
| Sensor Mount, Battery Operated |
Jual Digital Paddlewheel Flowmeter F-1000 Saddle Mount Fittings BLUE WHITE
Blue White – Digital Paddlewheel Flowmeter F-1000 Saddle Mount Fittings
Spesifikasi :
| Max. Working Pressure: | 300 psig (20 bar) @ 70°F (21°C) |
| Max. Fluid Temperature: |
200° F (93° C) @ 0 PSI (PVDF sizes) 140°F (60°C) @ 0 PSI (PVC sizes) |
| Full Scale Accuracy: | +/- 2% |
| Saddle Material: |
PVDF (1½”, 2″, 3″, 50mm, 63mm, 90mm sizes) PVC (all other sizes) |
| Sensor/ Paddle/ Axel Material: | PVDF |
| O-ring Material: | FKM (Optional EP) |
| Max. Pressure Drop: | 0 psi (no significant pressure drop) |
| Approx. Shipping Weight: | 2 lb. (0.91 kg) |
- Note: Maximum continuous flow should not occur in the upper 25% of the flow range. Refer to Instruction Manual
