Deskripsi
SPECIFICATION
Size : DN 15
Material : Head Epoxy Coated Aluminium, Body SS316L
Temperature : (-40)-120c
Pressure : 10800 psia Maximum Over Pressure
Power Suply : 24 VDC
Output : 4-20 mA HART
Protection Grade : IP 67
Connection : Screw
Accuracy : 0.04%
Measurement Range : 0-200 Kpa
Stability : 0.2% per 15 Years
Response Time : 90 ms
Repeatibility : –
Explosion Proof : –
Exida & TUV SIL Certified
Warranty 2 Years ( Full Service & Spare Parts )
APPLICATION
Measure differential pressure of Gas, Air, Steam, Liquid, Water, Various Solution, Spcial Fuild
