Model : pH Simulator
pH Simulation Values : ph 1.00, 1.68, 4.01, 6.86, 7.00,
9.18, 10.01 and 12.45
pH Simulation Accuracy : ±0.02 pH
mV Simulation Values : -1800, -900, -390, +390, +900
&+1800 mV
mV Simulation Accuracy : ±1 mV
High Impedance Test (Hi-Z) : 1012 Ohm at pH 4.01 & 10.01
PH Buffer Set standard : USA,NIST
Display : LED (Orange lighting)
Output : BNC connector
Power requirement : 4”AAA” Alkaline Batteries
Operating Temperature : 0 to 40°C
Relative Humidity : 80% up to 310°C decreasing
linearly to 50% at 400°C
(Ord No. EC-PHSIMULATOR)
PRECISION pH SIMULATOR
– Push Button pH/mV selection
– USA/NIST pH Buffer Standards simulation
– 16 combination values
– High Input Impedance test
– Large Easy to read display
– Rugged splash proof design
– Low Battery Indication
– Protective Rubber boot with stand
