Flow Meter Flo-Rite Oval Gear Meter LC-A10

Katalog :
Flo Rite Oval gear meter. Pdf

Main Features :

Cast Iron Oval Gear Meter Has The Ability To Handle a Wide Range of Fluid Viscosities With Exceptional Levels of Repeatability and Durability , Applying in The Petroleum , Chemical , Food Industry , etc.

Flow meter Oval Gear FLO RITE

MODEL :   LC – A10

Size   :   3/8”

Min. Flow Rate   :   0.8 L / min

Max. Flow rate    :   8 L / min

Accuracy   :   ± 0.5 %

Repeatability   :   ≤ 0.03 %

Max. Operating Pressure     :    18 Bar

Max. Operating Temperature    :    100ᴼC
