Digital Oval Gear Meter 1 Inch OGM-25E

Jual OGM Meter 1 Inch OGM-25E, Electronic Oval Gear Meter OGM 1″ DN25, Digital Oval Gear Meter OGM-25E Size 1 Inch, Digital Oil Flow Meter 1″, Flow Meter Digital 1 Inch

STANDARD SPECIFICATIONS

Katalog :
Digital Oval Gear Meter Pdf

OGM Meter Size:25 MM
Min.Flow Rite : 20 L/min
Max. Flow Rite : 120L/min
Accuracy : ±0.5%
Repeatability:≤0.03%
Max.viscosity:1000CPS
Working Pressure:0.3Mpa
One-Time Count Range:0.0-9999.9 L
Total Count Range:0.0-999999.9 L
Applicable Media :kerosene,Diasel,Gasonline



Deskripsi

Jual OGM Meter, Ready Stock Oval Gear Meter, Digital Oil Flow Meter OGM, Electronic OGM meter, OGM Flow Meter

OGM METERS :
The OGM series flow meters are positive displacement flow meter with Digital or Analog display, designed to cover a brand range of industrial fluid measurement applications. They are ideally suited to applications requiring accurate dispensing quantities, measurement of very low flow rates, small batch size, viscous products and non-conductive liquids are all ideal uses for this meter. Because this meter does not require flow conditioning, no straight piping is required, so it can be used in installations where space is limited without effecting performance. OGM meters are also available with digital preset option for high accuracy transfer of liquids. Liquids with viscosity of up to 1000 Cps can be easily handled with these meters.

Advantages:

  • Digital or Analog display, easy to read, aluminum body, PPS rotors, light weight.
  • 4 digitals subtotals can be set to zero, 6 digital total readout.
  • Compact size, easy maintenance, low pressure drop, quite operation.

Features :

  • Compact sizes – 1″ / 1.5″ / 2″
  • Easy maintenance
  • Meter with Totaliser and Reset option
  • Horizontal & vertical installation options
  • Low pressure drop
  • Viscosity up to 1000 Cps
  • Accuracy ± 0.5 %
  • Repeatability < 0.03 %
  • Pressure up to 34 Bar



Jual Digital Oval Gear Meter 1 Inch OGM-25E, Digital Oval Gear Meter 1,5 Inch OGM-40E, Digital Oval Gear Meter 2 Inch OGM-50E, Ready Stock Electronic Oval Gear Meter DN25 OGM-25E, Ready Stock Electronic Oval Gear Meter DN40 OGM-40E, Ready Stock Electronic Oval Gear Meter DN50 OGM-50E, Flow Meter Digital OGM 1″, Flow Meter Digital OGM 1.5″, Flow Meter Digital OGM2″, Jual Analog Oval Gear Meter 1 Inch OGM-A-25E, Jual Analog Oval Gear Meter 1,5 Inch OGM-A-40E, Jual Analog Oval Gear Meter 2 Inch OGM-A-50E, Flow Meter OGM Oval Gear Meter 1″ OGM-A-25E,Flow Meter OGM Oval Gear Meter 1,5″ OGM-A-40E, Flow Meter OGM Oval Gear Meter 2″ OGM-A-50E
